Product Overview

The SPF5043Z is a high-performance GaAs pHEMT MMIC low noise amplifier designed for 50MHz to 4000MHz wideband applications. With on-chip active bias network and integrated matching circuits, it delivers ultra-low noise figure, high linearity, and single-supply operation, making it ideal for high dynamic range receivers, wireless communication systems, and RF front-end modules.

Key Features

• Ultra-Low Noise Figure: Only 0.8dB at 900MHz ensures high-fidelity signal amplification.
• High Linearity Performance: OIP3 of 35dBm at 1900MHz supports large dynamic range signal processing.
• Wideband Coverage: Stable operation from 50MHz to 4000MHz for multi-standard communication systems.
• Simplified Single-Supply Design: 5V single-supply with integrated matching networks reduces PCB complexity.
• Industrial-Grade Reliability: Operates from -40°C to +85°C, suitable for harsh environments.

Technical Specifications

Typical Applications

• Wireless Communication Base Stations: Optimizes signal amplification in 5G/4G base station RF front-ends, enhancing system sensitivity and anti-interference capability.
• Satellite Communication Terminals: Supports wideband signal reception for efficient amplification of weak satellite signals.
• Industrial Automation: Ensures high-precision data acquisition in sensor networks for smart manufacturing and remote monitoring.
• Medical Equipment: High linearity design minimizes signal distortion in medical diagnostic devices for accurate bioelectrical signal analysis.
• IoT Devices: Low power consumption and wide temperature range enable long-term stable operation in smart sensors and remote terminals.

Why Choose SPF5043Z?

• Superior Signal Quality: 0.8dB ultra-low noise figure and 35dBm high OIP3 ensure minimal distortion during signal amplification.
• Flexible Power Supply: 3V to 5V adjustable voltage with 46mA typical current adapts to various power architectures.
• High Integration: Built-in matching networks and bias circuits reduce external components, accelerating development cycles.
• Harsh Environment Resilience: -40°C to +85°C operating range meets automotive and industrial requirements.
• Proven Market Reliability: Widely adopted in mobile and satellite communications, validated by large-scale commercial use.
