Product Overview

The LP2951ACMX-NOPB is a high-accuracy micropower voltage regulator by Texas Instruments (TI), designed for low-power systems with extremely low quiescent current (75μA typ.) and low dropout voltage (40mV at light loads, 380mV at 100mA). Supporting programmable output voltage from 1.24V to 29V, this 8-pin SOIC package regulator integrates an error flag and logic-controlled shutdown function. Ideal for battery-powered devices, portable electronics, and industrial controls, it ensures stable output while significantly extending battery life.

Key Features

• Ultra-Low Power Design：With a quiescent current of just 75μA typ., it minimizes power consumption, making it perfect for battery-driven IoT devices, wearables, and other power-sensitive applications.
• High-Precision Output：Features ±0.5% typical initial output voltage accuracy and excellent load/line regulation (±0.05% typ.), ensuring stable voltage supply for sensitive electronics.
• Low Dropout Voltage：Only 380mV typ. at 100mA load, enabling efficient operation with input voltages close to the output voltage, improving overall power efficiency.
• Integrated Protection Mechanisms：Built-in over-current and thermal shutdown protection safeguards against overloads and high temperatures, enhancing system reliability.
• Flexible Programmable Output：Adjustable output voltage from 1.24V to 29V via external resistors, supporting common voltages like 3V, 3.3V, and 5V for versatile applications.

Technical Specifications

Typical Applications

• ortable Electronics：Suitable for smartphones, tablets, and wearables, its ultra-low power consumption extends battery life, while low dropout voltage enables direct lithium battery power supply with minimal energy loss.
• Industrial Controls & Instruments：Provides stable power for PLCs and sensor modules, ensuring accurate signal acquisition with high output precision and wide temperature tolerance for industrial environments.
• IoT Sensors：Meets the low-power needs of sensor nodes, with programmable output adapting to various sensor voltage requirements and enhancing system flexibility.
• Battery-Powered Medical Devices：Delivers low noise and high stability for portable medical monitors, with over-current protection improving safety in critical applications.
• Backup Power Systems：Supports input voltages close to output voltage in UPS and emergency devices, ensuring continuous operation during power outages.

Why Choose LP2951ACMX-NOPB？

• Extreme Low Power：75μA quiescent current leads the industry, reducing system energy consumption for mobile devices reliant on battery life.
• Precision Voltage Regulation：±0.5% output accuracy and ±0.05% line regulation meet the strict requirements of precision electronics, ensuring stable power delivery.
• Wide-Range Adaptability：Supports 1.24V–29V output programming and -40°C–+125°C operation, making it suitable for diverse industrial and consumer applications.
• Reliable Protection：Internal over-current and thermal protection mechanisms safeguard against faults, enhancing system durability and safety.
• Compact & Efficient Design：SOIC package saves PCB space and supports low-ESR output capacitors, simplifying circuit design and reducing costs.
