Product Overview

The LM78L05ACMX/NOPB is a three-terminal positive voltage regulator by Texas Instruments (TI), designed to provide a stable 5V DC power supply. Housed in a low-profile SOIC-8 package, it delivers up to 100mA output current with built-in thermal overload protection and short-circuit current limiting. Requiring no external components, it offers efficient voltage regulation for logic systems, instrumentation, consumer electronics, and more. RoHS compliant, it serves as an ideal power solution for compact circuits.

Key Features

• High-Precision Voltage Output: Provides a 5V output with ±5% tolerance across the entire temperature range, ensuring stable power for voltage-sensitive devices.
• Robust Overload Protection: Built-in thermal overload and safe-area protection for output transistors prevent damage from overheating or short circuits, enhancing system reliability.
• Simplified Circuit Design: Operates without external components, requiring only input/output capacitors, which streamlines PCB layout and reduces design complexity and costs.
• Wide Temperature Adaptability: Operates from -40°C to +85°C, suitable for long-term stable performance in harsh environments like industrial control and automotive electronics.
• Eco-Compliant Packaging: Uses lead-free (RoHS compliant) SOIC-8 packaging, adhering to global environmental standards and supporting sustainable product design.

Technical Specifications

Typical Applications

• Consumer Electronics: Ideal for smartphone peripherals, portable chargers, and tablets, delivering stable 5V power to ensure reliable battery charging and data transmission.
• Industrial Control & Instrumentation: Powers sensors, embedded controllers, and measurement devices, operating stably in wide temperature ranges and resisting voltage fluctuations in industrial environments.
• Communication & Logic Systems: Supplies power to logic circuits in routers, switches, and MCU development boards, ensuring accurate digital signal processing.
• Hi-Fi Audio Equipment: Provides clean power for audio decoder chips and power amplifiers, minimizing noise interference and enhancing sound quality in audio systems.

Why Choose LM78L05ACMX/NOPB？

• Superior Voltage Regulation: Combines high-precision output with low quiescent current to reduce energy loss and improve power efficiency while filtering input ripple.
• Comprehensive Safety Protection: Built-in thermal and short-circuit protection eliminates the need for extra circuitry, safeguarding against overloads and temperature surges.
• Compact & User-Friendly Design: The small SOIC-8 package fits high-density PCBs, and its no-external-component requirement shortens development time and cuts material costs.
• Reliability in Harsh Conditions: Wide operating temperature range and industrial-grade durability ensure stable performance in complex environments like outdoor equipment and automotive electronics.
• Environmental Compliance: RoHS-compliant lead-free packaging meets international green standards, supporting eco-friendly supply chains and reducing regulatory risks.
