Product Overview

The CUS520.H3F(T is a silicon epitaxial Schottky barrier diode from Toshiba, optimized for high-speed switching applications. Housed in a USC package (equivalent to SOD-323 and SC-76), it features low reverse current (I_R(2)=5_µA max) and low forward voltage, supporting 30V reverse voltage and 300mA peak forward current. Ideal for high-frequency circuits, power rectification, and signal modulation, its compact design and wide temperature range (-40°C to 100°C) make it suitable for consumer and industrial electronics.

Key Features

• Ultra-Low Reverse Current: Maximum 5µA reverse current at 30V reduces energy loss and improves circuit efficiency.
• Compact Universal Package: USC package compatible with SOD-323/SC-76 enables high-density SMD mounting, saving PCB space.
• High-Speed Switching: Short reverse recovery time suits high-frequency switching applications for fast signal processing.
• Low Forward Voltage Drop: Typical 0.52V at 200mA forward current minimizes conduction loss for energy efficiency.
• Wide Temperature Operation: Operates from -40°C to 100°C, with storage from -55°C to 125°C, ensuring reliability in harsh environments.

Technical Specifications

Typical Applications

• High-Speed Switching Circuits: Used in high-frequency communication devices and pulse circuits for efficient signal transmission.
• Power Rectification & Polarity Protection: Functions as a rectifier in switch-mode power supplies or protects circuits from reverse polarity.
• Signal Modulation & Demodulation: Low forward voltage and high frequency response ensure signal integrity in analog modulation.
• Portable Electronics: Compact USC package and low power consumption suit smartphones and tablets, optimizing space and battery life.
• Industrial Automation: Wide temperature range supports stable operation in industrial environments for sensor signal conditioning or motor control.

Why Choose CUS520.H3F(T?

• Low Loss, High Efficiency: 5µA reverse current and 0.52V forward voltage minimize power loss, ideal for battery-powered devices.
• Space-Saving & Compatible: USC package supports standard SMD processes, simplifying PCB design and component sourcing.
• Stable High-Frequency Performance: Short reverse recovery time maintains reliability at MHz-level switching frequencies.
• Robust Temperature Tolerance: -40°C to 100°C operation ensures durability in automotive, industrial, and outdoor applications.
• Cost-Effective Solution: Integrates Schottky diode performance with compact packaging, eliminating the need for additional heat sinks.
