Product Overview

CMD175P4 is a 5-bit digital phase shifter based on GaAs MMIC technology, housed in a lead-free, RoHS-compliant 4x4 mm QFN package. It operates in the 2-4 GHz frequency range, providing 0-360° monotonic phase coverage with a minimum step (LSB) of 11.25°. Controlled by single-bit negative logic (0 or -3 V), the device features a 50Ω matched design, eliminating the need for external DC blocks and RF port matching components, thus delivering precise phase adjustment for RF systems.

Key Features

• Low Phase Error: Typical phase error of ±5°, ensuring high precision in phase adjustment, suitable for RF applications with strict phase accuracy requirements.
• Low Insertion Loss: Typical insertion loss of 7 dB, reducing energy loss during signal transmission and improving overall system efficiency.
• Full Phase Coverage: Achieves 360° complete phase adjustment with a minimum step of 11.25°, flexibly meeting various phase adjustment needs.
• Simplified Design: 50Ω matched design eliminates the need for external DC blocks and RF matching components, simplifying circuit design and shortening development cycles.
• Eco-Friendly and Reliable Package: Adopts a 4x4 mm lead-free QFN package, compliant with RoHS standards, suitable for high-density PCB layouts with good heat dissipation performance.

Technical Specifications

Typical Applications

• Communication Base Stations: In the RF front-end modules of base stations, CMD175P4 can be used for beamforming. By precisely adjusting signal phases, it optimizes signal coverage, improves communication quality, and enhances anti-interference capability.
• Radar Systems: Suitable for phase control circuits in radars, enabling phase modulation of detection signals, helping radars locate targets and measure distances more accurately, thus improving detection precision.
• Satellite Communication Equipment: In satellite transceiver systems, it can flexibly adjust the phase of RF signals, compensating for phase shifts during signal transmission, ensuring stable and reliable satellite communication.
• Test and Measurement Instruments: As a key component in RF test equipment, it provides adjustable phase signals for signal sources, meeting the demand for precise control of phase parameters in different test scenarios.

Why Choose CMD175P4?

• High-Precision Phase Control: Low phase error and 11.25° minimum step enable precise phase adjustment, meeting the requirements of high-performance RF systems.
• Excellent RF Performance: Low insertion loss, high return loss, and high linearity (typical input IP3 of 37 dBm) reduce signal distortion and ensure signal transmission quality.
• Design Convenience: No need for external matching components simplifies circuit design, reduces development difficulty and costs, and accelerates product launch.
• Wide Temperature Stability: Operating temperature range of -40 to 85 °C allows stable performance in extreme environments, adapting to various application scenarios.
• Eco-Compliance: Lead-free package and RoHS compliance align with green electronics manufacturing trends, suitable for export and markets with strict environmental requirements.
