Product Overview

The C8051F350-GQR is a high-performance mixed-signal System-on-Chip (SoC) based on the enhanced 8051 core, integrated with rich analog and digital peripherals, designed for industrial automation, medical instruments, and low-power embedded systems. It features a 24-bit high-precision ADC, dual 8-bit current-output DACs, a programmable comparator, and multi-protocol serial interfaces, offering 50 MIPS processing capability and a –40°C to +85°C wide temperature operation range. Its compact packaging and low-power design make it ideal for demanding performance and reliability scenarios.

Key Features

• Superior Analog Performance：
  Equipped with a 24-bit no-missing-code ADC (0.0015% nonlinearity), supporting 1 ksps programmable conversion rate and 8-channel multiplexer, with built-in programmable gain amplifier (1x to 128x) and temperature sensor, suitable for high-precision data acquisition.
• Flexible Digital Peripherals：
  Provides enhanced UART, SMBus™, and SPI™ interfaces, four 16-bit timers, and a programmable counter array (PCA) with capture/compare modules and watchdog function, meeting multi-device communication and real-time control needs.
• Low-Power Design：
  Typical operating current of 5.8 mA@25 MHz, standby mode current as low as 0.1 µA, supporting Idle and Stop modes, ideal for battery-powered devices and energy-efficient applications.
• On-Chip Debug and Storage：
  Built-in full-speed non-intrusive debug circuitry eliminates the need for an emulator; features 8 kB ISP Flash and 768 bytes of RAM, supporting in-system programming and data storage.
• Wide Temperature and Reliable Packaging：
  Housed in 28-QFN or 32-LQFP packages, operating from –40°C to +85°C with 5V-tolerant I/O pins, ensuring stability in harsh environments.

Typical Applications

• Industrial Automation Control：
  Implements high-precision analog signal acquisition and real-time control in PLCs and sensor nodes, supporting precise PWM for multi-axis motor drives via SPI/SMBus communication.
• Medical Instrumentation：
  Used in monitoring devices for biomedical signal processing, with 24-bit ADC ensuring low-noise data acquisition and low-power modes extending battery life.
• Smart Sensors：
  Adapts to signal conditioning for temperature, humidity, and pressure sensors. Built-in temperature sensor and PGA simplify front-end design, suitable for IIoT edge devices.
• Automotive Electronics：
  Meets in-vehicle diagnostic (OBD) and body electronics requirements, with wide temperature tolerance and noise immunity for engine compartment and in-vehicle network environments, supporting CAN bus cascading.
• Portable Devices：
  Enables low-power data processing in handheld meters and wearables, with Stop mode current as low as 0.1 µA. On-chip debugging accelerates development cycles.

Why Choose C8051F350-GQR？

• High-Performance Mixed-Signal Integration：
  24-bit ADC and dual DACs reduce external components, enhancing signal chain accuracy for industrial measurement and control.
• Energy Efficiency：
  Standby mode at 0.1 µA and dynamic clock management extend battery life, lowering system power costs.
• Rapid Development：
  On-chip debugging eliminates emulator needs, supporting In-System programming to reduce prototyping time and tool dependency.
• Wide Environmental Adaptability：
  –40°C to +85°C operation and 5V-tolerant I/O suit harsh industrial, automotive, and outdoor environments.
• Robust Ecosystem：
  Compatible with standard 8051 toolchains, offering evaluation boards and application guides for C language programming and complex algorithm implementation.
