Product Overview

The AD7416ARMZ-REEL 10-Bit Digital Temperature Sensor from the AD7416 series features an 8-lead mini small outline package (MSOP-8), integrating an on-chip temperature sensor and IC-compatible serial interface. Supporting a wide temperature range of -40°C to +125°C, it offers high precision and low power consumption, ideal for temperature monitoring and data acquisition in industrial control, consumer electronics, and automotive applications, providing real-time environmental temperature feedback and overheat protection.

Key Features

• High-Precision Measurement: 10-bit resolution enables 0.25°C/LSB temperature accuracy, with ±1°C error at 25°C and ±2°C over the full range, meeting stringent monitoring requirements.
• Wide Temperature Range: Operates from -40°C to +125°C, adapting to harsh industrial, automotive, and outdoor environments for stable performance.
• IC-Compliant Interface: Supports standard IC bus with configurable 7-bit device address via A0/A1/A2 pins, allowing up to 8 sensors on a single bus for easy multi-device networking.
• Low Power Design: Automatic power-down reduces consumption after conversion, with 600μA in normal mode and only 1.5μA in power-down mode, extending battery life for portable devices.
• Integrated Overheat Indicator: Built-in OTI (Overtemperature Indicator) with configurable thresholds via registers, offering open-drain output for alarm triggering in comparator/interrupt modes.

Technical Specifications

Typical Applications

• Industrial Process Control: Monitors equipment temperature in real time via IC bus, preventing overheating with OTI alarms to enhance system reliability.
• Automotive Battery Management: Adapts to vehicle temperature fluctuations, accurately measuring battery pack temperature to optimize charging safety and battery life.
• Consumer Electronics: Embedded in laptops and smartphones to monitor processor/battery temperature, optimizing power usage with auto-power-down for extended runtime.
• Environmental Monitoring Systems: Deployed in cold chain logistics and smart buildings for real-time temperature tracking, supporting multi-sensor networks for distributed control.

Why Choose AD7416ARMZ-REEL？

• Precision & Ruggedness: 10-bit resolution and wide temperature range ensure accurate monitoring in harsh industrial and automotive environments.
• Energy Efficiency: Low power-down consumption suits battery-powered devices, minimizing energy use during standby.
• Scalable Networking: IC interface supports up to 8 devices per bus, simplifying design and reducing costs for multi-sensor systems.
• Reliable Overheat Protection: Configurable OTI output enables timely alarms in two modes, enhancing device safety and fault tolerance.
• Miniature Form Factor: MSOP-8 package saves board space, ideal for compact, high-density designs in portable and IoT devices.
