54819-0572
- Manufacturer
- MOLEX
- Product Number
- 54819
- Description
- The 54819-0572 is a USB On-The-Go (OTG) Mini-B Right Angle Receptacle by Molex, featuring surface mount technology (SMT) with solder tails and shell tabs, covered by protective tape, and lead-free compliant.
- Inventory
- 20450
- Datasheet
-
54819-0572.pdf
- Delivery
-
- Payment
-
-
Product Overview
The 54819-0572 is a USB On-The-Go (OTG) Mini-B Right Angle Receptacle by Molex, featuring surface mount technology (SMT) with solder tails and shell tabs, covered by protective tape, and lead-free compliant. As a 5-circuit Mini-B interface, it enables direct device-to-device communication via OTG, ideal for compact wire-to-board connections in electronics, offering EMI resistance and high stability.
Key Features
- OTG Direct Connectivity：Supports peer-to-peer data transfer without a host, suitable for mobile storage and peripheral expansion.
- Right Angle SMT Design：90° bend saves PCB space, fitting narrow layouts for side-mounted installations.
- Gold-Plated Contacts：0.76μm gold plating (30.4μin) on contact areas enhances conductivity and oxidation resistance.
- Locking Mechanism：Positive lock with mating parts (Lock to Mating Part: Yes) ensures secure connections.
- Flame-Retardant & Eco-Friendly：UL94V-0 rated high-temperature thermoplastic housing, RoHS compliant, and lead-free.
Technical Specifications
Item Parameters Interface Type Mini-B OTG Receptacle Pitch 0.80mm (0.031") Circuits 5 Electrical - Max Current: 1A per contact
- Max Voltage: 30V
- Contact Resistance: ≤40mΩ (typical)Mechanical - Retention Force: ≥4.0N
- PCB Retention: YesPhysical - Orientation: Right Angle
- Housing: High-temperature thermoplastic (black)
- Metal: High Performance Alloy (HPA)Plating - Contact: 0.76μm Gold
- Termination: 1μm Tin (40μin)Temperature Range 0°C to +50°C Packaging Embossed Tape on Reel (ETR), 800 pcs/reel Compliance UL certified (E29179), RoHS compliant, halogen-free Typical Applications
- Mobile Peripherals：Connects smartphones/tablets to OTG devices like USB drives or card readers for direct data transfer.
- Consumer Electronics：Suitable for digital cameras, MP4 players, and other portables requiring compact charging/data interfaces.
- Industrial & Medical Devices：Ideal for small instruments needing reliable wire-to-board connections with secure mechanical fixation.
Why Choose 54819-0572？
- Dedicated OTG Design：Enables direct device communication, simplifying system architecture for mobile applications.
- Reliable Contact Performance：Gold plating reduces contact resistance, minimizing signal loss in high-frequency data transfer.
- Space-Saving Geometry：Right angle SMT design optimizes vertical space for thinner device profiles.
- EMI Shielding：Metal shield (Shielded: Yes) suppresses electromagnetic interference for clean signal integrity.
- Eco-Friendly & Process-Compatible：Lead-free design supports reflow soldering and meets global environmental standards for automated production.
