Product Overview

15-91-2140 is a 2.54mm pitch dual-row vertical surface mount header from Molex's C-Grid® series. Featuring phosphor bronze tin-plated terminals and a UL94V-0 fire-rated high-temperature thermoplastic housing, it offers 14-circuit dual-row design, SMT compatibility, and wide-temperature operation, ideal for consumer electronics, industrial control, and communication devices for reliable board-to-board/wire-to-board connections.

Key Features

• Standard Pitch & Dual-Row Design
  • 2.54mm (0.1") standard pitch fits mainstream PCB designs, with 14 circuits in dual rows for high-density signal transmission.
  • Vertical orientation enables space-saving vertical wiring and easy maintenance.
• Reliable Materials & Plating
  • Terminals made of phosphor bronze with tin plating (≥3.81μm) for oxidation and corrosion resistance, ensuring long-term conductivity.
  • Housing of UL94V-0 fire-rated thermoplastic (black) meets international safety standards for flame retardancy.
• Wide Environmental Adaptability
  • Operates in -40°C to +105°C temperature range, compatible with lead-free reflow soldering (max. 245°C for 30s).
• Stackable Flexibility
  • Stackable design supports multi-layer PCB expansion, suitable for complex system integration.
• Environmental Compliance
  • RoHS/China RoHS/ELV compliant, low-halogen, certified by UL (E29179) and CSA (LR19980).

Technical Specifications

Typical Applications

• Consumer Electronics: Ideal for expansion ports in laptops and desktops, supporting USB/audio signals with dual-row efficiency.
• Industrial Control: Used in PLCs and industrial computers for board-to-board connections, with wide temperature and fire-resistant features.
• Communication Equipment: Fits switches and routers, stackable design enables modular expansion for high-density wiring.
• Smart Home: Suitable for wire-to-board connections in smart speakers and control hubs, standard pitch simplifies mass production.

Why Choose 15-91-2140？

• Cost-Effective Standard Design: 2.54mm pitch reduces design complexity, ideal for large-scale procurement.
• SMT & Reflow Compatibility: Supports automated assembly with lead-free reflow soldering (3 cycles max).
• Global Compliance: UL/CSA certified and RoHS/low-halogen compliant for worldwide market access.
• Flexible Stackability: Enables multi-layer PCB stacking despite no locator pegs, relying on symmetrical dual-row alignment.
• Stable in Harsh Conditions: Operates reliably across wide temperatures, suitable for indoor/outdoor applications.
